GYRO AIR G1000 Industrial Dust Processor
Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Regular price
$10,900.00
Sale price
$13,900.00
Gyro Air G1000 Specifications
| Specifications | |
|
|
380-480V, 3 Phase 60Hz |
|
Breaker Size |
20A |
|
Inverter Type: |
Siemens V20 |
|
Motor Type |
TEFC Induction |
|
Power |
4 HP |
|
Phase |
3 Phase |
|
Rated Amps |
6.4A |
|
Motor Speed |
2400-4200 RPM (Variable Speed) |
|
Product Dimensions |
73-5/8" x 37" x 59" |
|
Shipping Dimensions |
81-1/4" x 43-1/4" x 68-1/8" |
|
Product Weight |
980 lbs |
|
Shipping Weight |
1200 lbs |
|
Max Air Flow |
1600 CFM |
|
Max Static Pressure |
25 inchwater |
| Specifications (Cont.) | |
|
Number of Filters |
3 |
|
Impeller Size |
14-1/8" |
|
Main Inlet Size |
6" |
|
Filter Emission Rating |
0.05mg/m³ |
|
Filter Efficiency |
99.95% @ 0.3 µm (HEPA) |
|
Filter Surface Area |
136 Sq. Ft |
|
Noise Rating @ 10ft |
61-72 dbA |
|
Max. Dust Bin Capacity |
40 Gal. |
|
Smart Jet pulse Filter Cleaning |
Yes |
|
Intelligent Dust-Full Monitoring System |
Yes |
|
Filter Monitor |
Yes |
|
Flow Cruise |
Yes |
|
Wireless Remote Control |
Yes |
|
wireless Synchornized Control |
Yes |
