AMBASSADOR C14Pro 3HP 14

AMBASSADOR C14Pro

3HP 14" Stain-less Bandsaw


$2,699.00$2,299.00

Flat Rate Shipping $299.00

* This shipping rate is only available for the lower 48 states.

* For other areas, please contact us for the detailed shipping rates.

* Tax and shipping freight will be calculated at checkout.


AMBASSADOR C14Pro

3HP 14" Stain-less Bandsaw

For many woodworkers, rust on bandsaws has long been a source of frustration. About ten years ago, Harvey began addressing this challenge by incorporating the TIN PVD Coating technology into products, reducing wear and rust on table saw surfaces.


However, Harvey is always striving for perfection. Five years ago, we started exploring the nickel plating technology. After countless tests on the process and formulation, we have successfully implemented optimal nickel plating technology on the tabletop, the cast iron flywheel and the Rack and Pinion Table Tilting System within the bandsaws, ensuring a literally rust-free experience for users by completely eliminating issues of wear and rust.

This superior nickel plating solution adopts the autocatalytic plating process, combining with a mid-phosphorus chemical nickel formula, significantly enhances wear resistance and rust prevention capabilities, resulting in a smoother and more lustrous finish.

Furthermore, the nickel-plated table surfaces achieved an impressive hardness of 500HV - 700HV, considerably improving their wear resistance. Extensive friction tests using wooden blocks consistently demonstrated that the nickel layer effectively protected the table surface.


We conducted a series of high-temperature and strong acid corrosion tests to evaluate the longevity of the nickel-plated surfaces. The results indicated that, under normal usage conditions, the nickel-plated surfaces could maintain their rust prevention performance for years. Notably, even in highly humid working environments, they exhibited exceptional rust prevention capabilities.


We are confident that the AMBASSADOR C14Pro Stain-less Bandsaw represents the ultimate solution to the rust problem in bandsaws. Guided by our steadfast philosophy that "Good Enough is Not Enough," this bandsaw exemplifies our unwavering dedication to innovation and precision.


What’s more, the AMBASSADOR C14Pro Stain-less Band saw features a powerful 3HP motor, 14" resaw capacity, super solid steel frame (over 350 Ibs in weight), heavy-duty cast iron flywheels, uniquely designed Tool-less blade guides, the newly developed COMPASS RG-2 Roller Guide for your safe and enjoyable cutting; foot brake with micro switch, magnetic on/off switch, rack and pinion table tilting system, quick- release tension as well as Harvey uncompromising fine craftsmanship.


For woodworkers seeking a bandsaw that combines traditional reliability with innovative features, the AMBASSADOR C14Pro is the ultimate choice. Experience the next level of industrial-grade woodworking machinery with Harvey Industries.


Features and Benefits

* Nickel-Plated Worktable For Superior Rust and Wear Resistance

* Nickel-Plated Cast Iron Rack and Pinion Table Tilting System

*Dynamically Balanced Cast Iron Flywheels with Nickel-Plating

*Powerful 3HP TEFC Single Phase Motor (220V)

*Extraordinary 14" Resaw Capacity

*Unique Tool-Less Upper and Lower Blade Guides

*COMPASS RG-2 Roller Guide

*Foot Brake with Micro Switch

*Quick Release Tensioning Levers


Nickel-plated worktable


The worktable undergoes a chemical nickel-plating process that bonds the nickel layer thickly to the base material, reaching an impressive hardness range of 500 HV to 700 HV, significantly enhancing its durability and resistance to corrosion and wear. Extensive friction tests using wooden blocks consistently demonstrated that the nickel layer can effectively protected the table surface.


Additionally, we performed a series of tests involving high temperatures and strong acids to determine the longevity of the nickel-plated surfaces. The results showed that, under normal conditions, the nickel-plated surfaces could retain their rust-preventive properties for many years. Impressively, they also exhibited excellent rust prevention in highly humid work environments.

A substantial 19-3/4" x 15-3/4" cast iron table offers a smooth surface for precise work.


Heavy Duty Cast Iron Flywheels

with Nickel-plating and Reinforced Structural Steel Frame


The nickel-plated Flywheels offer superior resistance to rust and wear, significantly extending their service life.

we performed a series of tests involving high temperatures and strong acids to determine the longevity of the nickel-plated surfaces. The results showed that, under normal conditions, the nickel-plated surfaces could retain their rust-preventive properties for many years. Impressively, they also exhibited excellent rust prevention in highly humid work environments. This ensures rust resistance and longevity, making the flywheels maintenance-free for rust prevention.

Dynamically balanced cast iron flywheels ensure smooth operation, minimal noise, and superior momentum for consistent cutting.


The reinforced solid steel frame provides remarkable rigidity and stability, enhancing durability and performance under the most demanding conditions.



Nickel-plated Cast Iron Rack

and Pinion Table Tilting System


The nickel plating of the entire Cast Iron Rack and Pinion Table Tilting System offers enhanced resistance to corrosion and wear, making the C14Pro virtually maintenance-free for rust prevention.

We carried out a series of high-temperature and strong acid corrosion tests to assess the durability of the nickel-plated components. The findings revealed that, under typical usage conditions, the nickel-plated surfaces could sustain their rust prevention performance for years. Remarkably, even in extremely humid working environments, they demonstrated outstanding rust prevention capabilities.

Precisely tilt the worktable from 45 degrees to -15 degrees using a Rack and Pinion Table Tilting System. Gas pistons assist in micro-adjustments, making the process smooth and straightforward.


Ball Bearing Blade Guides

 feature Tool-less Adjustment


The newly designed ball bearing blade guide has a ball bearing on each side of the blade and the back of the unit which ensures the minimum blade movement.

The tool-less adjustment and lock knobs are thoughtfully  designed to provide easy access and use.


Comes with

the COMPASS RG-2 Roller Guide

In order to enhance the operation safety and user experience of the C14Pro, our newly developed COMPASS RG-2 Roller Guide is in- cluded as standard accessor. The main body of RG-2 is made of anodized aircraft-grade aluminum with high precision machining and beautiful anodizing.

The Compass RG-2 Roller Guide utilizes an 'Independent Suspension Mechanism where each roller has its own pre-loaded spring. This design enables the two guide rollers to adapt to dynamic stock surfaces with consistent holding pressure by moving independently

The Self-locking Cam Structure allows for precise holding force adjustment by rotating the knob to optimize pressure for specific cutting situations. It offers an adjustable range of approximately 15-22 lbs(70-100 N),suitable for various cutting scenarios.


Powerful Motor

The 3 HP TEFC, industrial grade motor supplies the robust power needed for the large capacities of this band saw.


Foot Brake with Micro Switch

Immediately stops the saw blade when needed.


Specification



"Some images on this page are computer-generated representations of the product and may differ from the actual product. Colors, textures, and other details may not be accurately represented in the images. Please refer to the product description and specifications for more information."


ON SALE
AMBASSADOR C14Pro 3HP 14


AMBASSADOR C14Pro

3HP 14" Stain-less Bandsaw


$2,699.00$2,299.00


Flat Rate Shipping $299.00

* This shipping rate is only available for the lower 48 states.

* For other areas, please contact us for the detailed shipping rates.

* Tax and shipping freight will be calculated at checkout.

Customer Reviews

Based on 2 reviews
100%
(2)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
L
L.E. (Los Angeles, US)
Truly, a fantastic machine. Just a couple of issues.

First of all, this machine is wonderfully powerful, very smooth, very high-quality in engineering and materials and has proved to be a fantastic addition to my shop. One minor thing is that there is a gauge inside the upper cabinet next to the wheel that shows the tension on the blade. There’s a pointer that moves up and down on a graphic scale. On my machine, it did not work at all. It was not even connected to the tension mechanism. I had to add a spring that pulled up on the pointer arm so that it kept contact with the elevation of the tension device. Now it works well. This was not even mentioned in the instruction booklet. There’s even a little window where you can see this pointer without opening the upper wheel housing. Very odd. Considering how completely well-thought-out this machine is, I wonder why that happened. I also added a work light that is wired to the main switch. Most LED work lights now are dual voltage. I simply ordered one with a strong magnetic base and a gooseneck and removed the plug at the end, stripped and tinned the wires, added heat shrink tubing to toughen the end of the wire and provide a strain relief, and then I opened the switch housing. With the wiring diagram, I found the two wires that output the switched power to the motor and loosened the screws, slid those tinned wire tips inside the terminal clamps and re-tightened the terminal clamps. Using a rat tail file I filed a small groove in the edge of the switch housing and anchored the strain relief on the cable there. I reassembled the switch housing and using magnetic hooks, routed the wire safely to the top of the machine. Now I have a good strong work light that turns on with the motor and turns off as well. This is something I think should have been included in the original design of the machine. It would be simple to add a work light to this machine. All in all, it’s a fantastic machine. The price was reasonable as well. One pro tip for mounting it to the Mobile base they also sell. I use the strips of cardboard under the edges of the machine base that I had previously rubbed with paraffin on their underside. This allowed me to remove the bolts, anchoring the machine to the pallet. It was delivered on and slide it relatively safely, controllably, and easily onto the Mobile base which I lashed to the pallet. This made it possible to transfer a 300+ pound machine onto the mobile pace safely single-handedly. There is no contact of the machine and the mobile base in the process either. It came out perfectly. I’ll include a photo

J
J. (Brevard, US)
An excellent pro-sumer bandsaw

I love the saw. This is a beefy, well made and easy to use saw. The tooI-less blade guides are a breeze to use to set for a new blade. The dual dust ports help keep the interior of the saw mostly free of major sawdust and the table relatively clear. It was fully assembled on the pallet so I didn't need to do anything except move the power switch box, attach the allen key storage rack and install a blade.

I did find the tension indicator wasn't installed correctly as the upper pivot wasn't captured so it swung down freely. I contacted Support and they quickly provided me with instructions on how to get it right. Kudos to Support & considering the rest of the setup they did before shipping, I think I'm still better for them having done it and only needing to deal with the tension indicator.

I made a few modifications to the saw adding magnetic lights for the front window to use when switching blades to make sure it's riding on the wheel correctly and swapped out some of the knobs/handwheels. I replaced the table tilt and blade guard height adjusting handwheels with ones that had a right angle handle to make it easier to spin the wheels. I also replaced the blade guard tightening knob and the blade tilt tightening knob with lever bolts. This makes adjusting either of these a simple matter of flipping the lever and then using the adjusting wheels. I also replaced the lower thrust bearing wing bolt with a longer M8-40 socket cap screw to make it easier to loosen & tighten the thrust bearing. The wing bolt is hard to get at with your fingers if the table is horizontal. Replacing it with the M8 bolt allows me to reach it easily with one of the included allen wrenches.

One thing to note is the Stain-Less table is not "stainless" because I left a neodymium magnet on the table overnight and when I removed it the next day it left a ring. Even though it is much more forgiving than a cast iron table, it's still a good idea not to leave stuff on it that might mark it. I've treated it with Boeshield T-9 which should help and I wouldn't worry if I spilled a soda on it, but I'll still not leave things on the table overnight.
