In Stock

GYRO AIR G-700 Dust Processor

Dust Problems that Have Never Been Solved

In a woodworking shop, wood dust is always a big problem for woodworkers. Flying dust particles can severely harm not only the health of operators but also the environment. In past decades, woodworkers mostly used traditional dust collectors, such as bag collectors, or cyclone collectors.

However, all of these existing collectors have never really solved the problems, instead, they created more issues:

Very High Noise Levels (95-100 dB(A)) – constantly damages operators’ ears
Difficult Maintenance – filters are easily clogged by dust and need be cleaned frequently
Bulky Structure – it occupies a very large space in a woodworking shop
Large Power Consumption – normally requires 3 - 5 HP with expensive operating costs

Traditional Cyclone Dust Collectors

Cyclone dust collectors separate dusts by gravity. As gravity is not strong enough to push down small particles, only heavy dusts drop to dust tank. Up to 40% small dust particles are pushed up to filters which will be easily blocked, causing that the sucking static pressure drops rapidly. In addition, the dusty air flows in the cyclone and creates very large noise/vibration and energy consumption. All these problems have never been solved until now.

GYRO AIR G-700 Dust Processor

A Revolutionary Dust Processor

Because of the principal contradiction between dusty air flow and filtration, traditional dust collectors are struggling with filter clogging or bad air quality. Most of the dust collectors are very loud, bulky and difficult to maintain. This has been a long-standing pain for woodworkers.

To solve this problem, Harvey team of engineers spent over 7 years of research and study, to develop an unprecedented Dust Collector, the Gyro Air G-700 Wood Dust Processor. The G-700 Gyro Air Wood Dust Processor incorporates a unique, patented technology to separate dust particles from the air and capture them before they enter the filters.

The G-700 uses the new Axial Centrifugation Technology (called Gyro Airo Technology), to spin the air/dust stream up to 4,000 RPM and generate a super strong centrifugal force (over 100 times gravity) to separate the dust from the air and collect it in two dust bins hidden internally in the unit.

High Efficiency: 99.7% dust separation before filtration
Energy Saving:   Up to 50% energy saving (only 1.5KW)
Quiet:    Super low noise 61-72 dbA
Extremely Clean Emission: Filter emission rating 0.05mg/m3
Never Blocked:    Strong and stable static pressure

●Compact size with built-in mobility kit
●Strong and constant static pressure
●Filter Efficiency 99.35%@0.3~0.5μm
●Industrial motor and VFD speed control
●Intelligent dust- full monitor
●Remote control
●Power coated steel frame
●Steel dust separation system
●Convenient tool-less dust tank cleaning
●1-2 Dust port adapter
●Red Dot Design Award

GYRO AIR® Technology

High Efficiency
The Gyro Airo Dust Processor technology has revolutionized dust collecting. It was designed with Harvey's invention of Axial Centrifugation Technology (or called Gyro Air® Technology) which is completely different than any existing dust collector on the market. The Gyro Air Technology spins the flowing dust stream at high speeds (over 4000 rpm), which generates a significant centrifugal force on dust particles (over 100g) causing them to be pushed away from the air flow center and depositing them into dust tanks. The clean air remains in the chambers and any remaining fine particles are collected in the air filters.

With the new Axial Centrifugation Technology (called GYRO AIRO Technology), the G-700 can collect 99.7% of the dust particles before the air reaches its filters, which means much less cleaning of the flters without any clogging.

Energy Savings
Benefiting from the GYRO AIR® Technology and the VFD speed control system, the entire extraction system is aerodynamically optimized with extraordinary running efficiency, so it can
save up to 50% in energy costs.

Quiet
The GYRO AIR® technology and its unique aerodynamic design allow the G-700 GRYO AIRO to
run at an incredibly low noise level of 61 to 72 dB(A).

Extremely Clean Emission
The air emission cleanliness level from the filters can reach an unbeatable 0.05 mg/m3 (50% better than the European Standard of 0.1 mg/m3).

Convenient Tool-less Dust Tank Cleaning
The two dust bins are sealed when in use but are then easily accessed through a panel on the side of the unit, and they roll out for easy emptying (and you can use disposal bags to take out wood chips).
